Optical Isolator CORE

High Isolation
Low Insertion Loss
High Reliability
Rohs complaint
Compact Size
Optimized for different wavelengths

Features

  • High Isolation
  • Low Insertion Loss
  • High Reliability
  • Rohs complaint
  • Compact Size
  • Optimized for different wavelengths

Application

  • Transmitter Optical Sub Assembly(TOSA)
  • Bi-Directional Optical Sub Assembly(BOSA)
  • GPON/EPON OLT Module
  • Optical transmitters and transceivers
  • Optical sensor
  • Laser diode packaging
  • Tunable Laser Module

Specifications

Parameter Specification
Center Wavelength (nm) 1310+/-20nm; 1550+/-20nm
Single/Dual Stage Single Stage (w/o PMD) Single Stage (with PMD) Dual Stage
P Grade
Isolation (dB) (at λc) 1 Min 40 40 58
(at λc±20nm) 2 Min 26 26 48
Insertion Loss (dB) (at λc) 1 Typ 0.10 0.10 0.5
(at λc±20nm) 2 Max 0.15 0.15 0.6
PDL (dB) Max 0.05 0.05 0.1
PMD (ps) Max 0.25 0.05 0.05
Operating Temperature(°C) -5~+70
Storage Temperature (°C) -40~+85
Maximum Power Handling (mW) 500
Package Dimension (∅*L) (mm) 3.0*1.5 or 1.8*1.5 3.0*3.0 or 1.8*3.0
