Latching Optical Isolator

High Isolation
Low Insertion Loss
High Reliability
Rohs complaint

Features

  • High Isolation
  • Low Insertion Loss
  • High Reliability
  • Rohs complaint
  • Compact Size
  • Optimized for different wavelengths

Application

  • Transmitter Optical Sub Assembly(TOSA)
  • Bi-Directional Optical Sub Assembly(BOSA)
  • GPON/EPON OLT Module
  • Optical transmitters and transceivers
  • Optical sensor
  • Laser diode packaging
  • Tunable Laser Module

Specifications

Product Center Wavelength (λc)(nm) Isolation (λc 23℃)(dB) Insertion Loss (λc 23℃)(dB) Clear Aperture(mm) Operating Temperature
(℃)
Storage Temperature
(℃)
Max. Optical Power
(mW)
Single Stage Dual Stage Single Stage Dual Stage
Latching Isolator with Waveplate 1260-1650 >35 >55 <0.3 <0.5 Φ0.4~3.0 -40 to 85 -40 to 85 300
Latching Isolator Core >30 >50 <0.3 <0.6 Φ0.4~1.0 -40 to 85 -40 to 85 300



Product Center Wavelength (λc)(nm) Isolation (λc 23℃)(dB) Insertion Loss (λc 23℃)(dB) Clear Aperture(mm) Operating Temperature
(℃)
Storage Temperature
(℃)
Max. Optical Power
(mW)
Single Stage Dual Stage Single Stage Dual Stage
Latching Isolator with Waveplate 1260-1650 >38 >58 <0.2 <0.4 Φ0.4~3.0 -40 to 85 -40 to 85 300
Latching Isolator Core >32 >55 <0.2 <0.5 Φ0.4~1.0 -40 to 85 -40 to 85 300
