High Isolation
Low Insertion Loss
High Reliability
Rohs complaint
Product | Center Wavelength (λc)(nm) | Isolation (λc 23℃)(dB) | Insertion Loss (λc 23℃)(dB) | Clear Aperture(mm) | Operating Temperature (℃) |
Storage Temperature (℃) |
Max. Optical Power (mW) |
||
Single Stage | Dual Stage | Single Stage | Dual Stage | ||||||
Latching Isolator with Waveplate | 1260-1650 | >35 | >55 | <0.3 | <0.5 | Φ0.4~3.0 | -40 to 85 | -40 to 85 | 300 |
Latching Isolator Core | >30 | >50 | <0.3 | <0.6 | Φ0.4~1.0 | -40 to 85 | -40 to 85 | 300 |
