High Isolation
Low Insertion Loss
High Reliability
Rohs complaint
Compact Size
Optimized for different wavelengths
| Product | Center Wavelength (λc)（nm） | Isolation (λc 23℃)（dB） | Insertion Loss (λc 23℃)（dB） | Clear Aperture(mm) | Operating Temperature (℃) |
Storage Temperature (℃) |
Max. Optical Power （mW） |
||
| Single Stage | Dual Stage | Single Stage | Dual Stage | ||||||
| Free Space Isolator | 780 / 850 980 / 1060 1653 / 1685 / 2000 |
>35 | >55 | <0.3 | <0.5 | Φ0.4~3.0 | -40 to 85 | -40 to 85 | 300 |
| SMT Free Space Isolator | >35 | >50 | <0.3 | <0.6 | Φ0.4~3.0 | -40 to 85 | -40 to 85 | 300 | |
